![](http://www.hashima.co.jp/english/seihin-img/HP-1240MPindex.JPG) |
|
MODEL |
HP-1240MP |
POWER SUPPLY |
Three phase or Single phase |
RATED OUTPUT |
HEATER:3,650W |
MOTOR:400W |
MAX.TEMPERATURE |
200℃ |
MAX.PRESSURE |
210g/cm2 |
DIMENSION OF PLATE |
1,200×400mm |
DIMENSIONS |
950(D)×1,226(W)×1,340(H)mm |
WEIGHT |
(approx.) 210kg |
FEATURES |
□Motor driven fully-automatic flat type press. □Compact and requires no extra equipment such as an air compressor, and can be installed very easily. □Uses a special heater and the aluminium heater plates give excellent thermal efficiency and uniform temperature distribution. □Anti-static type Teflon sheet is used for the upper plate, making it easy to clean. □Although the suction system is automatic, pedal-operation is also possible (when using a tray, pedal-operation can not be used). Electrical contact-pointless components are used to improve the durability of the machine. □The powerful 200w blow motor provides extravacuum sucking power, and the sirocco fan is equipped to reduce noise.Sizes and spacings of the suction holes in the center part and around both ends on the lower plate have seen properly adjusted, to provide uniform sucking power over the entire surface. | | |
粘合衬参数参考表(青木制作) |
用衬类型 |
使用范围 |
温度(℃) |
压力(9.8×104Pa) |
时间(S) |
蒸汽复合压烫 |
手烫斗压烫 |
(外衣用) PA |
男外衣 |
150~170 |
0.3~0.5 |
15~20 |
可 |
差 |
女外衣 |
140~160 |
0.3~0.5 |
15~20 |
可 |
可 |
女衬衣 |
130~160 |
0.3~0.5 |
10~20 |
差 |
可 |
(表皮用) PA |
皮衣 |
100~160 |
0.1~0.4 |
6~20 |
好 |
好 |
(高密度) PE |
男衬衫 |
160~170 |
3~4.0 |
10~15 |
可 |
差 |
(低密度) PE |
小件服装 |
120~140 |
0.6~1.2 |
10~15 |
可 |
好 |
PES |
男女衬衫 |
140~160 |
0.3~0.5 |
10~16 |
差 |
差 |
EVA |
裘皮服装 |
80~120 |
0.1~0.3 |
8~12 |
好 |
好 |
青木公司服务Service: |
我们为您特备有24小时紧急服务电话全天候待命,一旦您购买的设备发生故障或使用中出现的问题,我们将第一时间为您电话解决或在最短的时间内赶到现场解决问题,保证您的生产不受影响。青木公司售后技术专线0-18602119933 |
青木公司技术Technology: |
我们拥有国内最专业技术力量及经验丰富的专业人员,售后服务完善,配件库存充足。 |
青木公司实力Strength: |
我们坚信,良好的服务是建立在齐全的产品及充裕的库存基础上的,因此,我们建立了庞大的库存仓库及完善的服务流程,相信你所需要的羽岛设备都能在我们的库存里找到.请放心使用我们提供的羽岛设备。您将得到我们优质的服务,同时将会得到青木专业的技术支撑!感谢您的支持! | |
